Key Features
1.Following UL1077 Standard, EN60934 Standard, IEC60934 Standard and complies with UL1500 ignition protection.
2.(Cadmium free contacts) Comply with European environmental protection requirements.
3.Use bakelite body, high temperature resistance, better safety.
4.Trip Free Cycling.
Ratings
1.Current rating range : 3--30A
2.Input voltage rating : 125/250VAC; 32/50VDC
3.Interrupting Capacity : 125/250VAC x 1,000A (UL 1077)
Testing Performed
1.Current test : 200% current full-inspect test
2.Dielectric strength test : 1500VAC/min
3.Glow wire test : 850 degree
Safety Certification
●Electrical appliances certification : UL, CSA, CB, VDE, TUV, CCC, SAA, KC
●Environmental standards : RoHS, REACH
